| Код | Кол-во | Примечание |
|---|---|---|
| 1 Коробка термостата | ||
|
001
|
|
|
| 2 gasket, coolant pump | ||
|
001
|
|
|
|
001
|
|
|
| 3 hexagon bolt, metric thread | ||
|
003
|
M8X80
|
|
| 4 hexagon bolt, metric thread | ||
|
002
|
M8X55
|
|
| 5 Плоская шайба | ||
|
001
|
|
|
| 6 coolant pump seal ring | ||
|
001
|
|
|
| 7 Вал насоса охлаждающей жидкости | ||
|
001
|
|
|
| 8 Сменное кольцо | ||
|
001
|
|
|
| 9 ball bearing, coolant pump | ||
|
002
|
|
|
|
002
|
|
|
| 10 Кольцо | ||
|
001
|
|
|
| 11 spring retaining ring for holes | ||
|
001
|
|
|
| 12 Ступица вентилятора | ||
|
001
|
|
|
| 13 gasket, coolant pump | ||
|
001
|
|
|
| 14 bolt with locking compound | ||
|
008
|
|
|
| 15 hexagon bolt, metric thread | ||
|
001
|
M10X20 8.8
|
|
| 16 thermostat, coolant | ||
|
002
|
|
|
| 17 Уплотнительное кольцо | ||
|
002
|
|
|
| 18 thermostat cover | ||
|
001
|
|
|
| 19 hexagon screw, metric thread | ||
|
002
|
M8X20 8.8
|
|
| 20 hexagon bolt, metric thread | ||
|
002
|
M8X60
|
|
| 21 spring washer, waved | ||
|
004
|
M8
|
|
| 22 male coupling, part for pipe coupling | ||
|
001
|
M22X1.5-M26X1.5
|
|
| 23 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 24 check nut | ||
|
001
|
M22X1,5
|
|
| 25 Трубка охлажд. жидк. | ||
|
001
|
|
|
| 26 union nut, part for pipe coupling | ||
|
001
|
M26X1.5,D=18mm
|
|
| 27 clamp-cutting ring, part for pipe coupling | ||
|
001
|
|
|
| 28 rectangular fixation plate | ||
|
002
|
|
|
| 29 pipe clip for 1 or 2 lines | ||
|
002
|
D=18,d=9mm
|
|
| 30 spring washer, arched | ||
|
002
|
M8
|
|
| 31 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 32 hexagon screw, metric thread | ||
|
002
|
M8X20 8.8
|
|
| 33 Шланг охлаждающей жидкости | ||
|
001
|
|
|
| 34 Хомут шланга | ||
|
002
|
D=19-28
|
|
| 35 Патрубок | ||
|
001
|
|
|
| 36 copper sealing washer | ||
|
001
|
33.3x38.9x2 mm
|
|
| 37 male coupling, part for pipe coupling | ||
|
001
|
M22X1.5-M26X1.5
|
|
| 38 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 39 check nut | ||
|
001
|
M22X1,5
|
|
| 40 coolant filling pipe | ||
|
001
|
|
|
| 41 union nut, part for pipe coupling | ||
|
001
|
M26X1.5,D=18mm
|
|
| 42 clamp-cutting ring, part for pipe coupling | ||
|
001
|
|
|
| 43 Шланг охлаждающей жидкости | ||
|
001
|
|
|
| 44 Хомут шланга | ||
|
002
|
D=19-28
|
|
| 45 sealing plug, non-metric thread | ||
|
001
|
1/2" BSTP
|
|
| 46 Шланг охлаждающей жидкости | ||
|
001
|
|
|
| 47 Хомут шланга | ||
|
002
|
D=19-28
|
|
| 48 shouldered stud | ||
|
001
|
|
|
| 49 copper washer | ||
|
001
|
|
|
| 50 Плоская шайба | ||
|
001
|
|
|
| 51 hexagon nut, metric thread | ||
|
001
|
M8
|
|
| 52 Насос охлаждающей жидкости, узел | ||
|
001
|
|
|
| 53 impeller assembly, coolant pump | ||
|
001
|
|
|
| 56 coolant pump impeller | ||
|
001
|
|
|
-+
