| Код | Кол-во | Примечание |
|---|---|---|
| 1 hose smaller than 16mm | ||
|
X
|
D=12mm,L=10M
|
|
| 2 reinforcement sleeve | ||
|
002
|
D=12
|
|
| 3 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=12
|
|
| 4 union nut, part for pipe coupling | ||
|
002
|
M18X1,5 D=12
|
|
| 5 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 6 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 7 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 8 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 9 pipe clip for 1 or 2 lines | ||
|
001
|
D=22,d=8.4mm
|
|
| 10 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 11 spring washer, arched | ||
|
001
|
M8
|
|
| 12 obtuse V-bracket | ||
|
001
|
|
|
| 13 bulkhead, part for pipe coupling | ||
|
001
|
|
|
| 14 check nut | ||
|
002
|
M18X1,5
|
|
| 15 bulkhead, part for pipe coupling | ||
|
001
|
|
|
| 16 Гибкий шланг | ||
|
002
|
C
|
|
| 17 reinforcement sleeve | ||
|
004
|
8X0.75 MM
|
|
| 18 clamp-cutting ring, part for pipe coupling | ||
|
004
|
D=12
|
|
| 19 union nut, part for pipe coupling | ||
|
004
|
M18X1,5 D=12
|
|
| 20 male coupling, part for pipe coupling | ||
|
002
|
|
|
| 21 Шатун | ||
|
002
|
|
|
| 22 coupling head, emergency line | ||
|
001
|
M16X1,5 RD
|
|
| 23 coupling head, service line | ||
|
001
|
M16X1,5 GL
|
|
| 24 hexagon screw, metric thread | ||
|
002
|
M8X30
|
|
| 25 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 26 spring washer, arched | ||
|
002
|
M8
|
|
| 27 L-bracket, 90 degrees | ||
|
001
|
|
|
| 28 hexagon screw, metric thread | ||
|
002
|
M8X20 8.8
|
|
| 29 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 30 spring washer, arched | ||
|
002
|
M8
|
|
| 31 flange bolt, metric thread, smooth | ||
|
004
|
M8X20 8.8
|
|
| 32 flange nut, hexagon, metric thread, smooth | ||
|
004
|
M8 8
|
|
-+
