| Код | Кол-во | Примечание |
|---|---|---|
| 1 reservoir, steering oil | ||
|
001
|
|
|
| 2 Хомут шланга | ||
|
002
|
D=120-140
|
|
| 3 Кольцо | ||
|
002
|
|
|
| 4 bracket, steering system | ||
|
001
|
|
|
| 5 flange bolt, metric thread, smooth | ||
|
002
|
M10X20X8.8
|
|
| 6 Гибкий шланг | ||
|
PM
|
D=31,L=2M
|
|
| 7 steering oil pipe | ||
|
001
|
|
|
| 8 Хомут шланга | ||
|
004
|
D=25-40
|
|
|
004
|
D=20-32
|
|
| 9 Гибкий шланг | ||
|
PM
|
D=24,S=4.5,L=1m
|
|
| 10 Хомут шланга | ||
|
002
|
D=16-25
|
|
| 11 Сопряжение типа банджо | ||
|
001
|
|
|
| 12 Пустотелый винт | ||
|
001
|
|
|
| 13 copper sealing washer | ||
|
002
|
18.2X23.9X1.5
|
|
| 14 Гибкий шланг | ||
|
001
|
|
|
| 15 clamp-cutting ring, part for pipe coupling smaller than 16mm | ||
|
002
|
|
|
| 16 union nut, part for pipe coupling | ||
|
002
|
M18X1,5 D=12
|
|
| 17 Сопряжение типа банджо | ||
|
001
|
M18X1,5
|
|
| 18 Пустотелый винт | ||
|
001
|
M16X1,5
|
|
| 19 sealing plug, part for pipe coupling | ||
|
001
|
|
|
| 20 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 21 steering oil pipe | ||
|
001
|
|
|
| 22 clamp-cutting ring, part for pipe coupling smaller than 16mm | ||
|
002
|
|
|
| 23 union nut, part for pipe coupling | ||
|
002
|
M18X1,5 D=12
|
|
| 24 bulkhead, part for pipe coupling | ||
|
001
|
M18X1,5-M18X1,5
|
|
| 25 check nut | ||
|
001
|
M18X1,5
|
|
| 26 hexagon bolt, metric thread | ||
|
003
|
M8X25
|
|
| 27 hexagon nut with non-metallic insert | ||
|
004
|
M8X1,25
|
|
| 28 pipe clip for 1 or 2 lines | ||
|
001
|
D=12,d=8.4mm
|
|
| 29 pipe clip for 1 or 2 lines | ||
|
003
|
D=22,d=8.4mm
|
|
| 30 Гибкий шланг | ||
|
PM
|
D=31,L=2M
|
|
| 31 steering oil pipe | ||
|
001
|
|
|
| 32 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=22mm
|
|
| 33 union nut, part for pipe coupling | ||
|
001
|
M30X2,D=22mm
|
|
| 34 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 35 copper sealing washer | ||
|
001
|
22.2x26.9x1.5mm
|
|
| 36 coupling, part for pipe coupling | ||
|
001
|
|
|
| 37 Гибкий шланг | ||
|
001
|
|
|
| 38 clamp-cutting ring, part for pipe coupling smaller than 16mm | ||
|
002
|
|
|
| 39 union nut, part for pipe coupling | ||
|
002
|
M18X1,5 D=12
|
|
| 40 male coupling, part for pipe coupling | ||
|
001
|
M16X1,5-M18X1,5
|
|
| 41 flange nut, hexagon, metric thread, smooth | ||
|
001
|
M8 8
|
|
| 42 flange bolt, metric thread, smooth | ||
|
001
|
M8X30
|
|
| 43 shouldered stud | ||
|
001
|
M8X8X20X20
|
|
|
001
|
|
|
-+
