| Код | Кол-во | Примечание |
|---|---|---|
| 1 solenoid valve block, ECAS single | ||
|
001
|
|
|
| 2 male coupling, part for pipe coupling | ||
|
003
|
|
|
| 3 seal ring, part for pipe coupling | ||
|
003
|
|
|
| 4 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 5 adjustable coupling, part for pipe coupling | ||
|
002
|
|
|
| 6 hexagon bolt, metric thread | ||
|
002
|
M8X75 8.8
|
|
| 7 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 8 spring washer, arched | ||
|
002
|
M8
|
|
| 9 Z-bracket | ||
|
001
|
|
|
| 10 hexagon bolt, metric thread | ||
|
002
|
M12X35 8.8
|
|
| 11 hexagon nut, metric thread | ||
|
002
|
M12 8
|
|
| 12 spring washer, arched | ||
|
002
|
M12
|
|
| 13 air reservoir bracket | ||
|
002
|
|
|
| 14 hexagon bolt, fine metric thread | ||
|
002
|
|
|
| 15 self-locking nut | ||
|
002
|
M10X1,25
|
|
| 16 flange bolt, metric thread, smooth | ||
|
004
|
|
|
| 17 flange nut, hexagon, metric thread, smooth | ||
|
004
|
M10
|
|
| 18 seal ring, part for pipe coupling | ||
|
008
|
|
|
| 19 bulkhead, part for pipe coupling | ||
|
001
|
|
|
| 20 check nut | ||
|
001
|
M22X1,5
|
|
| 21 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 22 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 23 Уплотн. заглушка | ||
|
003
|
M22X1.5X18
|
|
| 24 shouldered stud, fine thread | ||
|
001
|
|
|
| 25 check nut | ||
|
001
|
M22X1,5
|
|
| 26 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 27 blow-off valve | ||
|
002
|
HANDBEDIEND
|
|
| 28 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 29 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 30 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 31 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 32 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 33 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 34 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 35 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 36 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 37 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 38 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 39 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 40 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 41 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 42 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 43 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 44 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 45 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 46 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 47 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 48 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 49 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 50 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 51 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 52 male coupling, part for pipe coupling | ||
|
004
|
|
|
| 53 hose smaller than 16mm | ||
|
X
|
|
|
|
X
|
D=10mm,L=100M
|
|
| 54 reinforcement sleeve | ||
|
002
|
D=10
|
|
| 55 clamp-cutting ring, part for pipe coupling | ||
|
002
|
D=10mm
|
|
| 56 union nut, part for pipe coupling | ||
|
002
|
M16X1.5,D=10mm
|
|
| 57 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 58 adjustable coupling, part for pipe coupling | ||
|
002
|
|
|
| 59 seal ring, part for pipe coupling | ||
|
004
|
|
|
| 60 rectangular fixation plate | ||
|
002
|
|
|
| 61 plastic clamping strap | ||
|
X
|
L=203,B=7.6mm
|
|
| 62 L-bracket, 90 degrees | ||
|
002
|
115X35X25
|
|
| 63 hexagon bolt, metric thread | ||
|
002
|
M8X25
|
|
| 64 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 65 spring washer, arched | ||
|
002
|
M8
|
|
| 66 hexagon bolt, metric thread | ||
|
002
|
M10X25 8.8
|
|
| 67 hexagon nut, metric thread | ||
|
002
|
M10
|
|
| 68 spring washer, arched | ||
|
002
|
M10
|
|
-+
