| Код | Кол-во | Примечание |
|---|---|---|
| 1 Топливный бак | ||
|
001
|
V=200
|
|
| 2 L-bracket, omega profile | ||
|
002
|
|
|
| 3 rectangular fixation plate | ||
|
002
|
|
|
| 4 rectangular fixation plate | ||
|
002
|
|
|
| 5 hexagon bolt, fine metric thread | ||
|
008
|
M14FX40
|
|
| 6 hexagon nut, fine metric thread | ||
|
008
|
|
|
| 7 spring washer, arched | ||
|
008
|
M14
|
|
| 8 Датчик уровня топлива | ||
|
001
|
|
|
| 9 gasket, fuel float | ||
|
003
|
|
|
| 10 hexagon bolt, metric thread | ||
|
005
|
M 5X 8
|
|
| 11 Заправочная пробка, топливный бак | ||
|
003
|
|
|
| 12 Кольцоо для ключей | ||
|
006
|
|
|
| 13 Цепь | ||
|
003
|
|
|
| 14 omega bracket | ||
|
006
|
|
|
| 15 hexagon nut with non-metallic insert | ||
|
012
|
M12X1,25
|
|
| 16 hexagon bolt, fine metric thread | ||
|
012
|
M10X1.25X25
|
|
| 17 hexagon nut, fine metric thread | ||
|
012
|
M10X1,25
|
|
| 18 spring washer, arched | ||
|
012
|
M10
|
|
| 19 trimming section | ||
|
PM
|
|
|
| 20 fastening strap | ||
|
006
|
|
|
| 21 Топливная трубка | ||
|
001
|
L1=474
|
|
| 22 Топливная трубка | ||
|
001
|
|
|
| 23 sealing plug, fine metric thread | ||
|
008
|
M16X1,5
|
|
| 24 copper sealing washer | ||
|
010
|
16.2x21.9x1.3mm
|
|
| 25 flare coupling piece | ||
|
002
|
|
|
| 26 Топливный бак | ||
|
002
|
V=325
|
|
| 27 L-bracket, omega profile | ||
|
004
|
|
|
| 28 Фланец | ||
|
002
|
|
|
| 29 rectangular fixation plate | ||
|
004
|
|
|
| 30 hexagon bolt, fine metric thread | ||
|
016
|
M14FX40
|
|
| 31 hexagon nut, fine metric thread | ||
|
016
|
|
|
| 32 spring washer, arched | ||
|
016
|
M14
|
|
| 33 strainer, fuel tank | ||
|
001
|
|
|
| 34 strainer, fuel tank | ||
|
002
|
|
|
| 35 Топливная трубка | ||
|
001
|
|
|
| 36 rectangular fixation plate | ||
|
001
|
|
|
| 37 hexagon bolt, fine metric thread | ||
|
001
|
M14X1,5X35
|
|
| 38 hexagon nut, fine metric thread | ||
|
001
|
|
|
| 39 spring washer, arched | ||
|
001
|
M14
|
|
| 40 rectangular fixation plate | ||
|
002
|
|
|
| 41 hexagon bolt, metric thread | ||
|
002
|
M14X35X22
|
|
| 42 plain washer, hard | ||
|
002
|
15X28
|
|
| 43 spring washer, arched | ||
|
002
|
M14
|
|
| 44 hexagon nut, metric thread | ||
|
002
|
M14 8
|
|
| 45 flange for pipe coupling | ||
|
003
|
|
|
| 46 copper sealing washer | ||
|
006
|
M35
|
|
| 47 connecting bend, fuel tank | ||
|
003
|
|
|
| 48 hexagon screw, metric thread | ||
|
009
|
M8X30
|
|
| 49 spring washer, arched | ||
|
009
|
M8
|
|
| 50 plain washer, hard | ||
|
009
|
8.4x17x1.6 mm
|
|
| 51 Хомут шланга | ||
|
006
|
D=26-38mm
|
|
| 52 Гибкий шланг | ||
|
PM
|
D=39
|
|
| 53 Фиксатор выхл/труб. | ||
|
003
|
D=38,D1=7
|
|
| 54 hexagon bolt, metric thread | ||
|
006
|
M6X18
|
|
| 55 plain washer, normal | ||
|
006
|
M6
|
|
| 56 spring washer, arched | ||
|
006
|
M6
|
|
| 57 hexagon nut, metric thread | ||
|
006
|
M6
|
|
| 58 hexagon screw, metric thread | ||
|
010
|
M5X16
|
|
-+
