| Код | Кол-во | Примечание |
|---|---|---|
| 1 Воздушный компрессор | ||
|
001
|
|
|
| 2 Уплотнительное кольцо | ||
|
001
|
|
|
| 3 Шестерня привода компрессора | ||
|
001
|
|
|
| 4 flange bolt, metric thread, smooth | ||
|
001
|
|
|
| 5 plain washer, hardened | ||
|
001
|
|
|
| 6 flange bolt 10.9 | ||
|
004
|
M12X90
|
|
| 7 Кронштейн компрессора | ||
|
001
|
|
|
| 8 flange bolt 10.9 | ||
|
002
|
M8X16
|
|
| 9 flange bolt 10.9 | ||
|
002
|
M8X16
|
|
| 10 Кронштейн компрессора | ||
|
001
|
|
|
| 11 flange bolt 10.9 | ||
|
002
|
M8X16
|
|
| 12 oil pipe, delivery side | ||
|
001
|
|
|
| 13 clamp-cutting ring, part for pipe coupling | ||
|
001
|
d=6,D=9mm
|
|
| 14 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 15 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 16 copper sealing washer | ||
|
001
|
14.2x19.9x1.5mm
|
|
| 17 Пустотелый винт | ||
|
001
|
M12X24
|
|
| 18 copper sealing washer | ||
|
002
|
12x17x1.5 mm
|
|
| 19 compressor pipe, air dryer command | ||
|
001
|
|
|
| 20 clamp-cutting ring, part for pipe coupling | ||
|
001
|
d=6,D=9mm
|
|
| 21 union nut, part for pipe coupling | ||
|
001
|
M12X1.5 D=6mm
|
|
| 22 Пустотелый винт | ||
|
001
|
M12X24
|
|
| 23 copper sealing washer | ||
|
002
|
12x17x1.5 mm
|
|
| 24 quick-acting coupling, straight | ||
|
001
|
|
|
| 25 check nut | ||
|
001
|
M12X1,5
|
|
| 26 pipe clip for 1 or 2 lines | ||
|
001
|
D=6,d=6.4mm
|
|
| 27 hexagon screw, metric thread | ||
|
001
|
M6X22mm
|
|
| 28 flange nut, hexagon, metric thread, smooth | ||
|
001
|
M6
|
|
| 29 Трубка охлажд. жидк. | ||
|
001
|
|
|
| 30 Пустотелый винт | ||
|
001
|
M14X26
|
|
| 31 copper sealing washer | ||
|
002
|
14.2x19.9x1.5mm
|
|
| 32 Пустотелый винт | ||
|
001
|
|
|
| 33 copper sealing washer | ||
|
002
|
16.2x21.9x1.3mm
|
|
| 34 coolant return hose, compressor outlet | ||
|
001
|
|
|
| 35 Сопряжение типа банджо | ||
|
001
|
|
|
| 36 Пустотелый винт | ||
|
001
|
|
|
| 37 copper sealing washer | ||
|
002
|
16.2x21.9x1.3mm
|
|
| 38 Сопряжение типа банджо | ||
|
001
|
|
|
| 39 Пустотелый винт | ||
|
001
|
M14X26
|
|
| 40 copper sealing washer | ||
|
002
|
14.2x19.9x1.5mm
|
|
| 41 Хомут шланга | ||
|
002
|
|
|
| 42 compressor pipe 01, delivery side | ||
|
001
|
|
|
| 43 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 44 union nut, part for pipe coupling | ||
|
002
|
M26X1.5,D=18mm
|
|
| 45 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 46 copper sealing washer | ||
|
001
|
26.3x33.9x2 mm
|
|
| 47 bulkhead, part for pipe coupling | ||
|
001
|
|
|
| 48 check nut | ||
|
001
|
M26X1,5
|
|
| 49 Патрубок | ||
|
001
|
|
|
| 50 copper sealing washer | ||
|
001
|
30.3x35.9x2 mm
|
|
| 51 Сопряжение типа банджо | ||
|
001
|
|
|
| 52 copper sealing washer | ||
|
001
|
26.3x33.9x2 mm
|
|
| 53 hollow bolt | ||
|
001
|
M26X1,5
|
|
| 54 Уплотн. заглушка | ||
|
001
|
M32X1,5
|
|
| 55 compressor pipe 01, suction side | ||
|
PM
|
|
|
| 56 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=22mm
|
|
| 57 union nut, part for pipe coupling | ||
|
001
|
M30X2,D=22mm
|
|
| 58 Фиксатор выхл/труб. | ||
|
001
|
|
|
| 59 flange nut, hexagon, metric thread, smooth | ||
|
001
|
M8-10
|
|
| 60 shouldered stud | ||
|
001
|
|
|
| 61 copper sealing washer | ||
|
001
|
|
|
| 62 Кронштейн компрессора | ||
|
001
|
|
|
| 63 check nut | ||
|
001
|
M22X1,5
|
|
| 999 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=22mm
|
|
|
001
|
d=6,D=9mm
|
|
|
002
|
|
|
|
001
|
M14X26
|
|
|
001
|
M12X24
|
|
|
001
|
|
|
|
001
|
|
|
|
001
|
M32X1,5
|
|
|
001
|
|
|
|
001
|
|
|
|
001
|
|
|
|
001
|
|
|
-+
