| Код | Кол-во | Примечание |
|---|---|---|
| 1 Дифференциал раздат. коробки | ||
|
001
|
1355
|
|
| 2 differential cover | ||
|
001
|
|
|
| 3 oil seal cover | ||
|
001
|
|
|
| 4 seal ring, differential | ||
|
001
|
|
|
| 5 Закрывающ. кожух | ||
|
001
|
|
|
| 6 drive flange, differential | ||
|
001
|
|
|
| 7 Фланцевая гайка | ||
|
001
|
|
|
| 8 flange bolt 10.9 | ||
|
006
|
M10X25 10.9
|
|
| 9 Калибров. прокладка | ||
|
X
|
S=0.076
|
|
|
X
|
S=0.120
|
|
|
X
|
S=0.250
|
|
|
X
|
S=0.500
|
|
|
X
|
S=1.000
|
|
| 10 tapered roller bearing, differential | ||
|
001
|
|
|
| 11 differential axle | ||
|
001
|
|
|
| 12 shifting ring | ||
|
001
|
|
|
| 13 Упорный подшипник | ||
|
001
|
|
|
| 14 Планетарная шестерня | ||
|
001
|
|
|
| 15 Втулка для суппорта | ||
|
002
|
|
|
| 16 flange bolt 10.9 | ||
|
018
|
M12X35
|
|
| 17 Крестовина | ||
|
001
|
|
|
| 18 Калибров. прокладка | ||
|
004
|
|
|
| 19 Сателлит | ||
|
004
|
|
|
| 21 tapered roller bearing, differential | ||
|
001
|
|
|
| 22 Планетарная шестерня | ||
|
001
|
|
|
| 23 Втулка для суппорта | ||
|
001
|
|
|
| 24 Блок дифференциала | ||
|
001
|
|
|
| 25 cylindrical dowel pin | ||
|
004
|
|
|
| 26 flange bolt 10.9 | ||
|
004
|
M16X120
|
|
| 28 flange bolt 10.9 | ||
|
008
|
M12X55
|
|
| 29 differential axle | ||
|
001
|
|
|
| 30 ball bearing, differential | ||
|
001
|
|
|
| 31 spring retaining ring for holes | ||
|
001
|
|
|
| 32 seal ring, differential | ||
|
001
|
|
|
| 33 cap, differential, rear | ||
|
001
|
|
|
| 34 drive flange, differential | ||
|
001
|
|
|
| 35 Фланцевая гайка | ||
|
001
|
|
|
| 36 pinion housing | ||
|
001
|
|
|
| 37 flange bolt 10.9 | ||
|
012
|
M12X35
|
|
| 38 Калибров. прокладка | ||
|
X
|
S=0.076
|
|
|
X
|
S=0.12
|
|
|
X
|
S=0.25
|
|
|
X
|
S=0.50
|
|
|
X
|
S=1.00
|
|
| 39 tapered roller bearing, differential | ||
|
001
|
|
|
| 40 Кольцо | ||
|
001
|
|
|
| 41 plug with sealing compound | ||
|
001
|
|
|
| 42 Калибров. прокладка | ||
|
X
|
S=5.30
|
|
|
X
|
S=5.50
|
|
|
X
|
S=5.60
|
|
|
X
|
S=5.65
|
|
|
X
|
S=5.75
|
|
|
X
|
S=5.80
|
|
|
X
|
S=5.90
|
|
|
X
|
S=6.10
|
|
|
X
|
S=6.45
|
|
| 43 Ось подшипника | ||
|
001
|
|
|
| 44 Пружина компрессора | ||
|
001
|
|
|
| 45 shift fork, differential | ||
|
001
|
|
|
| 46 hexagon socket set screw, metric thread | ||
|
001
|
M10X25
|
|
| 47 hexagon nut, metric thread | ||
|
001
|
M10 04
|
|
| 48 Уплотнительное кольцо | ||
|
001
|
|
|
| 49 Поршень | ||
|
001
|
|
|
| 50 flange bolt 10.9 | ||
|
003
|
M8X55
|
|
| 51 cover, differential lock | ||
|
001
|
|
|
| 54 pneumatic cylinder, differential lock | ||
|
001
|
|
|
| 55 tapered roller bearing, differential | ||
|
001
|
|
|
| 56 gear, differential | ||
|
001
|
|
|
| 57 Зубчатое колесо и шестерня | ||
|
001
|
I=1:4.49
|
|
| 58 Фланцевая гайка | ||
|
001
|
|
|
| 59 Идент. пластина | ||
|
001
|
|
|
| 60 tapping screw with raised cheese head and hexalobular recess | ||
|
002
|
|
|
| 61 cylindrical dowel pin | ||
|
002
|
10M6X24 mm
|
|
| 62 plug with sealing compound | ||
|
001
|
3/4-14 NPTF
|
|
| 63 Регулировочная гайка | ||
|
002
|
|
|
| 64 tapered roller bearing, differential | ||
|
002
|
|
|
| 65 Планетарная шестерня | ||
|
002
|
|
|
| 66 Калибров. прокладка | ||
|
002
|
|
|
| 67 Сателлит | ||
|
004
|
|
|
| 69 Крестовина | ||
|
001
|
|
|
| 70 Калибров. прокладка | ||
|
004
|
|
|
| 71 Ось подшипника | ||
|
001
|
|
|
| 72 Пружина компрессора | ||
|
001
|
|
|
| 73 shift fork, differential | ||
|
001
|
|
|
| 74 hexagon socket set screw, metric thread | ||
|
001
|
M10X25
|
|
| 75 hexagon nut, metric thread | ||
|
001
|
M10 04
|
|
| 76 Уплотнительное кольцо | ||
|
001
|
|
|
| 77 Поршень | ||
|
001
|
|
|
| 78 flange bolt 10.9 | ||
|
003
|
M8X55
|
|
| 79 cover, differential lock | ||
|
001
|
|
|
| 82 pneumatic cylinder, differential lock | ||
|
001
|
|
|
| 83 Кольцо | ||
|
001
|
|
|
| 84 shifting ring | ||
|
001
|
|
|
| 85 Стопорное разрезное кольцо | ||
|
001
|
|
|
| 86 hexagon screw, metric thread | ||
|
004
|
M8X12
|
|
| 87 Стопорная шайба | ||
|
002
|
|
|
| 88 Штифт цилиндрический | ||
|
002
|
|
|
| 89 flanged bolt | ||
|
016
|
|
|
| 90 plain washer, hardened | ||
|
008
|
|
|
| 91 hexagon bolt, fine metric thread | ||
|
008
|
|
|
| 92 hexagon nut, fine metric thread | ||
|
008
|
|
|
| 93 spring retaining ring for shafts | ||
|
002
|
|
|
| 94 retainer cap | ||
|
001
|
|
|
| 95 differential gasket | ||
|
001
|
|
|
| 96 flange gasket, differential | ||
|
001
|
|
|
| 97 differential gasket | ||
|
001
|
|
|
| 98 flange gasket, differential | ||
|
001
|
|
|
| 99 retainer cap | ||
|
001
|
|
|
| 100 hexagon screw, fine metric thread | ||
|
X
|
|
|
| 101 satellite housing, differential | ||
|
001
|
|
|
| 102 satellite housing, differential | ||
|
001
|
|
|
| 103 protective cap, differential | ||
|
002
|
|
|
| 104 Калибров. прокладка | ||
|
X
|
S=7,5
|
|
|
X
|
S=7,75
|
|
|
X
|
S=8,0
|
|
|
X
|
S=8,25
|
|
|
X
|
S=8,50
|
|
|
X
|
S=8,75
|
|
|
X
|
S=9
|
|
-+
