| Код | Кол-во | Примечание |
|---|---|---|
| 1 hexagon bolt, fine metric thread | ||
|
004
|
|
|
| 2 spring washer, arched | ||
|
004
|
M14
|
|
| 3 hexagon nut, fine metric thread | ||
|
004
|
|
|
| 4 bracket, trailing axle lifting mechanism | ||
|
001
|
|
|
| 5 welded precision pipe with special requirements, zinc-coated | ||
|
PM
|
D=8,L=6M
|
|
| 6 clamp-cutting ring, part for pipe coupling | ||
|
002
|
|
|
| 7 union nut, part for pipe coupling | ||
|
002
|
M14X1.5,D=8mm
|
|
| 8 straight reducer, part for pipe coupling | ||
|
001
|
|
|
| 9 male coupling, part for pipe coupling | ||
|
002
|
M22X1,5-M22X1,5
|
|
| 10 Электромагнитный клапан | ||
|
001
|
|
|
| 11 multi-core wire | ||
|
PM
|
|
|
| 12 Уплотнительная заглушка | ||
|
001
|
D1=32,B=3
|
|
| 13 Патрубок | ||
|
001
|
|
|
| 14 Электроподключение | ||
|
002
|
0.8 - 2.5
|
|
| 15 part for pipe coupling, general | ||
|
001
|
|
|
| 16 adjustable coupling, part for pipe coupling | ||
|
001
|
M22X1,5
|
|
| 17 pipe coupling, complete | ||
|
001
|
|
|
| 18 hose smaller than 16mm | ||
|
PM
|
D=15,L=10M
|
|
| 19 reinforcement sleeve | ||
|
002
|
15
|
|
| 20 clamp-cutting ring, part for pipe coupling | ||
|
002
|
15
|
|
| 21 union nut, part for pipe coupling | ||
|
002
|
M22X1.5 D=15
|
|
| 22 male coupling, part for pipe coupling | ||
|
001
|
M22X1,5-M22X1,5
|
|
| 23 Бак, ресивер, емкость | ||
|
001
|
|
|
| 24 Затяжной хомут | ||
|
002
|
|
|
| 25 hexagon bolt, fine metric thread | ||
|
001
|
M10X1.25X25
|
|
| 26 self-locking nut | ||
|
001
|
M10X1,25
|
|
| 27 hexagon bolt, fine metric thread | ||
|
004
|
M10X1.25X25
|
|
| 28 spring washer, arched | ||
|
004
|
M10
|
|
| 29 hexagon nut, fine metric thread | ||
|
004
|
M10X1,25
|
|
| 30 hexagon bolt, fine metric thread | ||
|
002
|
M10FX20
|
|
| 31 spring washer, arched | ||
|
002
|
M10
|
|
| 32 hexagon nut, fine metric thread | ||
|
002
|
M10X1,25
|
|
| 33 Фиксатор выхл/труб. | ||
|
001
|
D=112,D1=11
|
|
| 34 Насос системы смазки | ||
|
001
|
|
|
| 35 hexagon bolt, metric thread | ||
|
002
|
M8X65
|
|
| 36 spring washer, arched | ||
|
002
|
M8
|
|
| 37 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 38 КрепЁжный угольник | ||
|
001
|
|
|
| 39 hexagon bolt, metric thread | ||
|
002
|
M8X25
|
|
| 40 plain washer, hard | ||
|
002
|
8.4x17x1.6 mm
|
|
| 41 spring washer, arched | ||
|
002
|
M8
|
|
| 42 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 43 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 44 copper sealing washer | ||
|
001
|
26.3X31.9X2mm
|
|
| 45 part for pipe coupling, general | ||
|
001
|
|
|
| 46 pipe, cooling system | ||
|
001
|
|
|
| 47 clamp-cutting ring, part for pipe coupling | ||
|
001
|
|
|
| 48 union nut, part for pipe coupling | ||
|
001
|
M26X1.5,D=18mm
|
|
| 49 pipe coupling, complete | ||
|
001
|
|
|
-+
