| Код | Кол-во | Примечание |
|---|---|---|
| 1 bracket, engine lubrication system | ||
|
001
|
|
|
| 2 Уплотнительное кольцо | ||
|
002
|
D=29.75
|
|
| 3 flange bolt, metric thread, smooth | ||
|
002
|
M10X60
|
|
|
002
|
M10X60
|
|
| 4 straight coupling piece | ||
|
001
|
|
|
| 5 Элем. масл. фильтр | ||
|
001
|
|
|
|
001
|
|
|
| 6 flange bolt, metric thread, smooth | ||
|
002
|
M10X25 8.8
|
|
| 7 copper sealing washer | ||
|
001
|
18.2X23.9X1.5
|
|
| 8 Патрубок | ||
|
001
|
|
|
| 9 engine oil cooler | ||
|
001
|
|
|
| 10 Уплотнительное кольцо | ||
|
002
|
D=33
|
|
| 11 hexagon bolt, metric thread | ||
|
002
|
M10X40 8.8
|
|
|
002
|
M10X35 10.9
|
|
| 12 shouldered stud | ||
|
002
|
|
|
| 13 Плоская шайба | ||
|
004
|
|
|
| 14 sealing plug, fine metric thread | ||
|
001
|
M14X1,5
|
|
| 15 copper sealing washer | ||
|
001
|
14.2x19.9x1.5mm
|
|
| 16 air bleed pipe | ||
|
001
|
|
|
|
001
|
|
|
| 17 Пустотелый винт | ||
|
002
|
M14X26
|
|
| 18 copper sealing washer | ||
|
004
|
14.2x19.9x1.5mm
|
|
| 19 air bleed pipe | ||
|
001
|
|
|
|
001
|
|
|
| 20 flange gasket, oil sump | ||
|
001
|
|
|
| 21 hexagon bolt, metric thread | ||
|
003
|
M8X25
|
|
| 22 hexagon bolt, metric thread | ||
|
001
|
M8X14
|
|
|
001
|
M8X14
|
|
| 23 pipe clip for 1 or 2 lines | ||
|
001
|
D=30,D1=8.4
|
|
| 24 flange bolt, metric thread, smooth | ||
|
001
|
M8X20 8.8
|
|
|
001
|
M8X20 10.9
|
|
| 25 flange nut, hexagon, metric thread, smooth | ||
|
001
|
M8 8
|
|
| 26 Гибкий шланг | ||
|
001
|
L=700,D=30
|
|
| 27 Хомут шланга | ||
|
001
|
D=26-38mm
|
|
|
001
|
D=32-44
|
|
| 28 filler cap, oil filling pipe | ||
|
001
|
|
|
| 29 Трубка уровнемера | ||
|
001
|
|
|
|
001
|
|
|
| 30 clamp-cutting ring, part for pipe coupling | ||
|
001
|
15
|
|
| 31 union nut, part for pipe coupling | ||
|
001
|
M22X1.5 D=15
|
|
| 32 flange bolt, metric thread, smooth | ||
|
002
|
M8X20 8.8
|
|
|
002
|
M8X20 10.9
|
|
| 33 dipstick, engine | ||
|
001
|
|
|
|
001
|
|
|
| 34 Уплотнительное кольцо | ||
|
001
|
|
|
-+
