| Код | Кол-во | Примечание |
|---|---|---|
| 1 КрепЁжный угольник | ||
|
001
|
|
|
| 2 hexagon bolt, metric thread | ||
|
001
|
M12X30 8.8
|
|
| 3 hexagon nut, metric thread | ||
|
001
|
M12 8
|
|
| 4 spring washer, arched | ||
|
001
|
M12
|
|
| 5 hose smaller than 16mm | ||
|
PM
|
|
|
|
PM
|
D=10mm,L=100M
|
|
| 6 reinforcement sleeve | ||
|
001
|
D=10
|
|
| 7 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=10mm
|
|
| 8 union nut, part for pipe coupling | ||
|
001
|
M16X1.5,D=10mm
|
|
| 9 Электромагнитный клапан | ||
|
001
|
|
|
| 11 hexagon bolt, metric thread | ||
|
002
|
M8X80
|
|
| 12 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 13 spring washer, arched | ||
|
002
|
M8
|
|
| 14 adjustable coupling, part for pipe coupling | ||
|
002
|
|
|
| 15 male coupling, part for pipe coupling | ||
|
002
|
|
|
| 16 seal ring, part for pipe coupling | ||
|
002
|
|
|
| 17 Гибкий шланг | ||
|
001
|
C L=590,D=9
|
|
| 18 clamp-cutting ring, part for pipe coupling smaller than 16mm | ||
|
002
|
|
|
| 19 union nut, part for pipe coupling | ||
|
002
|
M18X1,5 D=12
|
|
| 20 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 21 seal ring, part for pipe coupling | ||
|
001
|
|
|
| 22 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 23 test connector, pneumatic, female | ||
|
001
|
M18X1,5
|
|
| 24 bulkhead, part for pipe coupling | ||
|
001
|
|
|
| 25 check nut | ||
|
001
|
M12X1,5
|
|
| 26 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 27 Электромагнитный клапан | ||
|
002
|
|
|
| 28 hexagon bolt, metric thread | ||
|
002
|
M8X110 8.8
|
|
| 29 hexagon nut, metric thread | ||
|
002
|
M8
|
|
| 30 spring washer, arched | ||
|
002
|
M8
|
|
| 31 straight reducer, part for pipe coupling | ||
|
002
|
|
|
| 32 adjustable coupling, part for pipe coupling | ||
|
002
|
|
|
| 33 bulkhead, part for pipe coupling | ||
|
001
|
|
|
| 34 seal ring, part for pipe coupling | ||
|
002
|
|
|
| 35 reinforcement sleeve | ||
|
001
|
D=10
|
|
| 36 clamp-cutting ring, part for pipe coupling | ||
|
001
|
D=10mm
|
|
| 37 union nut, part for pipe coupling | ||
|
001
|
M16X1.5,D=10mm
|
|
| 38 Z-bracket | ||
|
001
|
|
|
| 39 hexagon screw, metric thread | ||
|
001
|
M8X20 8.8
|
|
| 40 hexagon nut, metric thread | ||
|
001
|
M8
|
|
| 41 spring washer, arched | ||
|
001
|
M8
|
|
| 42 hexagon bolt, metric thread | ||
|
002
|
M6X20 8.8
|
|
| 43 coupling, part for pipe coupling | ||
|
001
|
|
|
| 44 Фиксатор выхл/труб. | ||
|
002
|
D=6,D1=7
|
|
| 45 welded precision pipe with special requirements, zinc-coated | ||
|
PM
|
D=6mm,L=6M
|
|
| 46 clamp-cutting ring, part for pipe coupling | ||
|
002
|
d=6,D=9mm
|
|
| 47 union nut, part for pipe coupling | ||
|
002
|
M12X1.5 D=6mm
|
|
| 48 welded precision pipe with special requirements, zinc-coated | ||
|
PM
|
D=6mm,L=6M
|
|
| 49 clamp-cutting ring, part for pipe coupling | ||
|
002
|
d=6,D=9mm
|
|
| 50 union nut, part for pipe coupling | ||
|
002
|
M12X1.5 D=6mm
|
|
| 51 welded precision pipe with special requirements, zinc-coated | ||
|
PM
|
D=6mm,L=6M
|
|
| 52 clamp-cutting ring, part for pipe coupling | ||
|
002
|
d=6,D=9mm
|
|
| 53 union nut, part for pipe coupling | ||
|
002
|
M12X1.5 D=6mm
|
|
| 54 Гибкий шланг | ||
|
001
|
C
|
|
| 55 Двухпутевой клапан | ||
|
001
|
|
|
| 56 male coupling, part for pipe coupling | ||
|
002
|
|
|
| 57 adjustable coupling, part for pipe coupling | ||
|
001
|
|
|
| 58 seal ring, part for pipe coupling | ||
|
003
|
|
|
| 59 coupling, part for pipe coupling | ||
|
001
|
|
|
| 60 male coupling, part for pipe coupling | ||
|
001
|
|
|
| 61 adjustable coupling, part for pipe coupling | ||
|
001
|
M18X1,5
|
|
| 62 adapter bush | ||
|
002
|
15X9X14
|
|
| 63 check nut | ||
|
001
|
M14X1,5
|
|
| 64 spring washer, arched | ||
|
002
|
M6
|
|
| 65 hexagon nut, metric thread | ||
|
002
|
M6
|
|
| 66 plain washer, normal | ||
|
001
|
M6
|
|
-+
